Carriage House WOOD Garage Doors


Our Carriage House Collection door begins
with the following:

  • 1-3/8" thick Douglas Fir stile and rail frame, which features mortised and tenoned joints, that are glued and steel pinned for superior strength at all stile and rail joints.
  • Next, ¼" exterior grade Lauan (Mahogany) is laminated and steel pinned to the interior side of the 1-3/8" door frame. Other types of materials may also be used upon request.
  • 1-3/8" thick polystyrene insulation is individually cut and put into place between the stiles and rails of every frame. Doors that require a higher R-Value can be filled with other insulation options.
  • ¼" exterior grade Lauan (Mahogany), 3/8" Breckenridge Plywood, 3/8" Medium Density Overlay (MDO) or other specified material is then laminated and stainless steel pinned to the exterior side of the 1-3/8" door frame.
  • All sections are machined to provide clean, straight edges to ensure tight (almost seamless) section joints.
  • Exterior trim materials, as specified by the consumer / builder / architect, are attached to the exterior side of the overlay to provide the specified design.
  • Every trim board joint has been reinforced by the installation of a #20 biscuit to ensure long-lasting seamless trim joints.
  • Individual sections are cut at an angle of 15-degrees to shed water away from the door and keep the section horizontal sight lines minimal.
  • Overall thickness of the door is approximately 3" depending on the exterior overlay material and the trim material that has been specified.
See our models:
Model 443 - S
Model 643 - S
Model 646 - SA
Model 747 - S
Model 747 - SA
Model 547 - RA
Model 227 - R

Cut Away of Typical Carriage House Door


Carriage House Door Carriage House Door Carriage House Door Carriage House Door Carriage House Door Carriage House Door Carriage House Door
